Product Details
＋
| GPU |
AMD Radeonô RX 7900 XTX Graphics Card |
| 5nm GPU | |
| AMD RDNAô 3 Architecture | |
|
Engine Clock |
Boost Clock: Up to 2500 MHz |
| Game Clock: Up to 2300 MHz | |
| Boost Clock is the maximum frequency achievable on the GPU running bursty workload. Boost clock achievability, frequency, and sustainabilty will vary based on several factors, including but not limited to: thermal conditions and variation in application and workloads. | |
| Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP(Total Graphics Power). Actual individual game clock results may vary. | |
|
Stream Processors |
6144 |
|
Compute Units |
96 CU (with RT AI Accelerators) |
|
Infinity Cache |
96MB |
|
Ray Accelerators |
96 |
|
Memory Size/Bus |
24GB GDDR6 |
|
Memory Clock |
20 Gbps Effective |
|
Displays |
Maximum 4 Displays |
|
Resolution |
HDMIô: 7680◊4320 |
| DisplayPort 2.1: 7680◊4320 | |
| USB-C: 7680x4320 | |
|
Interface |
PCI-Express 4.0 x16 |
|
Output |
1x HDMI |
| 2x DisplayPort | |
| 1x USB-C | |
|
BIOS Support |
UEFI |
|
Game Index |
4K |
|
AMD Features |
AMD RDNAô 3 Gaming Architecture |
| 96 AMD RDNAô 3 Compute Units (with RT AI Accelerators) | |
| 96MB AMD Infinity Cacheô technology | |
| DisplayPortô 2.1 | |
| AMD Radiance Displayô Engine | |
| AMD Radeonô Boost technology* | |
| AMD Radeonô Anti-Lag* technology* | |
| 24GB GDDR6 on 384-Bit Memory Bus | |
| PCIÆ Express 4.0 ready | |
| AMD FidelityFXô technologies* | |
| AMD FidelityFXô Super Resolution technology* | |
| MicrosoftÆ DirectXÆ 12 Ultimate | |
| MicrosoftÆ DirectStorage | |
| VulkanÆ Optimized | |
| AMD smart technologies* | |
| AMD Software: Adrenalin Editionô application | |
| AMD Noise Suppression* | |
| AMD Privacy View* | |
| AMD Radeonô Super Resolution technology* | |
| AMD Link* | |
| AMD Freesyncô technology | |
|
Cooler Type |
3 Fans |
|
Form Factor |
2.5 slot, ATX |
| Dimension: 287(L)X 123.2(W)X 51.25 (H)mm | |
|
Power Consumption |
346W |
|
OS |
LinuxÆ, WindowsÆ 10, and Windows 11. 64-bit operating system required |
|
System Requirement |
Minimum 800 Watt Power Supply |
| 2 x 8-pin Power Connector. |
